PAR-64 housing short

• Rugged metal housing
• Heat-resistant fixing screw
• 4 clip-to-hold clamps with spring locks for comfortable opening of the color filter frame
• Safety grille (splinter protection) is integrated in the tube
• Strong clamps with extension springs for safe hold and for quick opening of the rear housing cover
• Strong cable tension relief
• Blackened tube for precise light output
• Control via plug and play
• With Mounting bracket
• Available in various colors
• For PAR 64
• For application areas such as: Trade fair and shop fitting; Clubs/dancing school; Stage

Package contents

• 1 x spotlight, 1 x filter frame, 1 x lamp clamping ring, 1 x user manual

Power supply:
230 V AC, 50 Hz
Power consumption:
Max. 1000 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Fixed Supply cord with open wires
Cable length:
Approx. 0,7 m
Base:
GX16d
Lamp type:
Selectable
Color generation:
Via color filter frame
Control:
Plug and play
Housing color:
Black
Attachment system:
Mounting bracket
Material:
Metal
Slot for spot length:
25,7 cm x 25,7 cm
Dimensions:
Length: 27,5 cm
Width: 26,5 cm
Height: 34,5 cm
Weight:
1,4 kg
Filter frame
Material:
Metal
Dimensions:
Length: 25,5 cm
Width: 2,5 cm
Diameter: Ø 20,2 cm
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
