Flat spotlight with 6 x 8 W 3in1 LED with RGB color mixing

• Slim design for space-saving applications
• DMX and power terminals intelligently designed for easy wiring
• 6 powerful LEDs 8 W high-power 3in1 TCL RGB (homogenous color mix)
• Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic
• Strobe effect
• 2 integrated show programs
• Direct color selection for 16 preset colors
• The device is cooled by cooling fan
• Control via stand-alone; DMX; Sound to light via Microphone; Master/slave function
• Flicker-free
• With a beam angle of 16°
• With Mounting bracket
• 4 digit 7-segment LED display
• Mains input and output for power linking up to 8 units
• Preprogrammed in EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; LED PC-Control 512; Light Captain; EASY SHOW 2; EASY SHOW 3
• Rubber feet
• Application possibility: Standing; suspended

Package contents

• 1 x spotlight, 1 x power cord, 1 x user manual

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
15 W
IP classification:
IP20
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug included
Power output:
1 x IEC connector (F) mounting version
Lamp type:
LED lamp
LED:
6 x 8 W high-power 3in1 TCL RGB (homogenous color mix)
Flash rate:
0 - 20 Hz
DMX channels:
2; 3; 4; 5; 7
DMX input:
1 x 3-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version
Cooling:
1 x cooling fan
Control:
Stand-alone; DMX; Sound to light via Microphone; Master/slave function
Preprogrammed in:
EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; LED PC-Control 512; Light Captain; EASY SHOW 2; EASY SHOW 3
Beam angle:
16°
Beam angle (1/2 peak):
16°
Beam angle (1/10 peak):
30°
Housing color:
Black
Attachment system:
Mounting bracket
Display type:
4 digit 7-segment LED display
Transport aid:
Rubber feet
Material:
Plastic; ABS Acrylonitrile butadiene styrene
Dimensions:
Width: 22 cm
Depth: 11 cm
Height: 21 cm
Weight:
1,16 kg
Photobiological safety:
Risk Group 0
Power cord
Cable construction:
3 x 0,75 mm² H05VV-F
Cable length:
Approx. 1,2 m
Mounting bracket
Diameter mounting holes:
5 x Ø11mm
Material:
Metal, 2 mm
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
