600 Watts peak, (300 Watts continuous Class D power) The newly designed horn delivers greater coverage 90° H x 60° V The full grille delivers style and provides protection for your investment. 12-inch (305 mm) LF driver, 2-inch (50.8 mm) voice coil 1-inch (25.4 mm) neodymium HF compression driver with 1-inch voice coil Lightweight, portable design for main or wedge monitor operation Standard speaker pole socket Bi-amplified design with precision active crossover and EQ Balanced XLR/TRS with selectable Mic/Line input. XLR Link Output, Contour EQ switch and Ground-Lift switch Designed and tuned in the USA

SPECIFICATIONS
Power Output: 600 Watts peak, 300 Watts continuous Class D power
LF Driver: 12-inch (305 mm) LF driver, 2-inch (50.8 mm) voice coil
HF Driver: 1-inch (25.4 mm) neodymium HF compression driver with 1-inch voice coil
Crossover: 2.5 kHz
Maximum: 118 dB at 1m
Frequency Response: (-3dB): 70 Hz–20 kHz
Horn Coverage: 90° H x 60° V nominal
Equalization: Contour Switch Low and High Frequency +3dB Boost
Connectors: (1) XLR/TRS ¼” (6.35 mm) combo input, (1) XLR link output, (1) IEC power cable input
Controls: (1) Volume, Power on/off switch, Contour switch, Ground-Lift Switch
Indicators: (2) Power LED (front and rear), Clip limiter LED
Protection: Overload Analog Limiter / Compressor, Thermal Protection
Power Supply: 100V-240V ~ 50/60Hz
AC Voltage Input: 100,110-120,220–240 V, 50/60 Hz
Fuse: 100–120V T4AL AC250V, 220–240V T2AL AC250V
Power Consumption: 260 W
Enclosure Construction: Injection-molded polypropylene enclosure, multi-angle for main or
monitor applications, metal grille, rubber feet, 2 handles (both sides)
Mounting/Installation: Standard speaker pole socket, Wedge Monitor
Dimensions (HxWxD): 23.7" x 15" x 13.7" / 602mm x 381mm x 348mm
Net Weight: 31.3 lbs. / 14.2 kg

Alto TX212
