Monitor, 12" woofer, 1.35" driver, LF: 250 W RMS, HF: 50 W RMS

• Active 2-way coaxial stage monitor for live and playback applications
• Class D/AB biamp power amplifier
• 30 cm bass speaker (12") and 3.5 cm compression driver (1.35")
• Bassreflex cabinet provides deep bass and high SPL
• Line input (XLR/6.3 mm jack)
• Low cut, volume control
• Black metal grille
• Application possibility: Standing; monitoring; on tripod

Package contents

• 1 x compact cabinet speaker, 1 x user manual, 1 x power cord

Power supply:
115/230 V AC, 50/60 Hz
Power consumption:
180 W 1/8 power
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power:
Program: 500W
Rated: 50W RMS HF
Rated: 250W RMS LF
Frequency range:
50 - 20000 Hz
Max. SPL:
123 dB
Dispersion angle:
80° x 80°
Controls:
Limiter; overload
Connections:
Input: line via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Output: line via 1 x 3-pin XLR
Input channels:
1 x mono via XLR or jack, channel control via Rotary dial
Speaker:
1 x woofer (12") approx. 30 cm with ferrit magnet
1 x Voice coil compression tweeter highs (1.35") approx. 3.5 cm
Type of speaker:
Compact cabinet speaker; Coaxial speaker; stage monitor
Type of construction:
Vented
Material:
MDF (Medium-density fibreboard)
Color:
Black, textured coating, painted
Dimensions:
Width: 50 cm
Depth: 34 cm
Height: 46 cm
Weight:
16,70 kg
