DMX-controlled surface light with 168 dual white LEDs, QuickDMX port and barn doors

• 84 powerful LEDs 0,5 W SMD 2835 warm white (WW)
• 84 powerful LEDs 0,5 W SMD 2835 cold white (CW)
• Variable color temperature 2800 K - 6500 K
• 4 barn doors to avoid blinding the audience and for protection during transport
• Energy-saving, durable and environmentally friendly
• Pulse-width modulation variable
• Integrated show programs
• The device is cooled by passive convection cooling
• Control via Quick select potentiometer for brightness and color temperature; stand-alone; DMX; Master/slave function; Sound to light via Microphone; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional)
• Flicker-free
• With a beam angle of 120°
• Good color rendering index (CRI)
• With Mounting bracket
• 4 digit 7-segment LED display
• Slim, rugged metal housing
• For application areas such as: Video and photography; Stage
• Preprogrammed in Light Captain
• Available in various colors
• Mains input and output for power linking up to 8 units

Package contents

• 1 x spotlight, 1 x user manual, 1 x power cord

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
40 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power output:
1 x IEC connector (F) mounting version
Fuse:
T 1 A Fuse replaceable
Lamp type:
LED lamp
LED:
84 x 0,5 W SMD 2835 warm white (WW)
84 x 0,5 W SMD 2835 cold white (CW)
Color temperature:
2800K - 6500K adjustable
Flash rate:
0 - 20 Hz
DMX channels:
2; 4; 6
DMX input:
3-pin XLR (M) mounting version
DMX output:
3-pin XLR (F) mounting version
Cooling:
Passive convection cooling
Control:
Quick select potentiometer for brightness and color temperature; stand-alone; DMX; Master/slave function; Sound to light via Microphone; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional)
Preprogrammed in:
Light Captain
Beam angle:
120°
Beam angle (1/2 peak):
120°
Color rendering index (CRI):
80 Ra
Illuminance in Lux (lx):
Cold white (CW) 1m: 539 lx, 3m: 73 lx, 6m: 21 lx
Warm white (WW) 1m: 529 lx, 3m: 72 lx, 6m: 21 lx
All 1m: 1063 lx, 3m: 143 lx, 6m: 43 lx
Housing color:
Black
Attachment system:
Mounting bracket
Display type:
4 digit 7-segment LED display
Dimensions:
Width: 28,1 cm
Depth: 11,0 cm
Height: 17,3 cm
Weight:
1,84 kg
Photobiological safety:
Risk Group 0
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
