ALUTRUSS QUADLOCK 6082-3000 4-Way Cross Beam

4-point truss system

• Strong EN-AW 6082 alloy for high loads
• High-quality aluminum-tubes with 50 mm in diameter
• Low weight
• Distance center - center: 240 mm
• Easy installation
• Trusspipe: 50 mm
• TÜV Süd certified
• For application areas such as: Theater; Trade fair and shop fitting; Clubs/dancing school
• For further information about this product, please refer to the Data Sheet under "Downloads"

Package contents

• 1 x connection Set

ALUTRUSS QUADLOCK 6082L-30 3-Way Corner 90°

4-point truss system

• Strong EN-AW 6082 alloy for high loads
• High-quality aluminum-tubes with 50 mm in diameter
• Low weight
• Distance center - center: 240 mm
• Easy installation
• Trusspipe: 50 mm
• Made in Europe
• For application areas such as: Theater; Trade fair and shop fitting; Clubs/dancing school

Package contents

• 2 x connection Set

ALUTRUSS QUICK-LOCK Spare Pivot with Pin

QUICK-LOCK set

• Accessories for the robust truss system with Quick-Lock
• For use with TRI/QUAD system
• Trusspipe: 50 mm
• Made in Europe

ALUTRUSS QUADLOCK End Plate QQGP-Male M-10

Baseplate for mobile use (connectors 6082 included)

• Easy installation
• The article is delivered pre-assembled
• Trusspipe: 50 mm
• Made in Europe
• Application possibility: Standing

half cone

• M10 thread

Package contents

• 1 x plate, 4 x half cone

Weight:
151,94 kg
ALUTRUSS QUADLOCK 6082-3000 4-Way Cross Beam
Setup:
Easy installation
Trusspipe:
50 mm x 2 mm
Welding technique:
TIG-welding
Welding material:
AlMg 5
Alloy:
AIMgSi1 T6
Color:
Alu colored
Strut diameter x thickness:
16 x 2mm
Dimensions:
Length: 3 m
Width: 29 cm
Height: 29 cm
Weight:
14,2 kg
ALUTRUSS QUADLOCK 6082L-30 3-Way Corner 90°
Setup:
Easy installation
Trusspipe:
50 mm x 2 mm
Color:
Alu colored
Strut diameter x thickness:
16 x 2mm
Dimensions:
Length: 50 cm
Width: 50 cm
Height: 50 cm
Weight:
7,95 kg
ALUTRUSS QUICK-LOCK Spare Pivot with Pin
Trusspipe:
50 mm
Color:
Alu colored
Weight:
90 g
ALUTRUSS QUADLOCK End Plate QQGP-Male M-10
Setup:
Easy installation
Trusspipe:
50 mm
Material:
Aluminum
Color:
Alu colored
Dimensions:
Length: 30,7 cm
Width: 30,7 cm
Height: 5 cm
Weight:
1,55 kg
Half cone
Thread:
M10 thread
