ALUTRUSS TRILOCK 6082-2000 3-Way Cross Beam

3-point truss system

• Low weight
• Easy installation
• Trusspipe: 50 mm
• TÜV Süd certified
• For application areas such as: Theater; Trade fair and shop fitting; Clubs/dancing school
• For further information about this product, please refer to the Data Sheet under "Downloads"

Package contents

• 1 x connection Set

ALUTRUSS Truss Transport Board Combo for 3 Wheels

Transport cart for QUADLOCK and TRILOCK truss elements

• Practical transport cart made of multiplex wood
• Suitable for QUADLOCK and TRILOCK truss elements with 290 mm
• Quick and secure stacking with optional stacking ridges
• Cut-outs for safety bands for safe transport of the truss elements
• Grip hole
• 12 borings for mounting castors (optional)
• The combination of 2 transport carts and 10 stacking ridges allows transport of 12 truss elements (recommended maximum load)
• Made in Germany

ROADINGER Swivel Castor 100mm BLUE WHEEL light blue

100 mm swivel castor

• Double ball race
• Housing made of steel, zinc-plated
• Roller race hub bearing
• Replaceable bolt-on wheel
• Carrying capacity: 450 kg per set (4 castors)
• Made in Germany
• For further information about this product, please refer to the Data Sheet under "Downloads"

ROADINGER Swivel Castor 100mm BLUE WHEEL with brake

100 mm swivel castor

• Double-action brake (wheel and swivel)
• Double ball race
• Housing made of steel, zinc-plated
• Roller race hub bearing
• Replaceable bolt-on wheel
• Carrying capacity: 450 kg per set (4 castors)
• Made in Germany
• For further information about this product, please refer to the Data Sheet under "Downloads"

ROADINGER Bolt Set for Wheels

Complete set (4 x screw, 4 x nut, 4 x washer)

• Screw: hexagon screw M8 x30 DIN933 galvanized
• Nut: hexagon screw Kl.8 M8 DIN 934 galvanized
• Washer: size 8.4 DIN125 electrogalvanized

ALUTRUSS Truss Transport Ridge Combo

Stacking rail for QUADLOCK and TRILOCK truss elements

• Stacking ridge for quick and secure stacking of truss elements on matching transport carts
• Suitable for QUADLOCK and TRILOCK truss elements with 290 mm
• Made in Germany

SHZ Clamping Belt S400 Ratchet 5m/25mm black

Clamping belt

• LC400/800daN surroundings
• Complies with EN 12195-2
• Ratchet lock

Weight:
79,58 kg
ALUTRUSS TRILOCK 6082-2000 3-Way Cross Beam
Setup:
Easy installation
Trusspipe:
50 mm x 2 mm
Welding technique:
TIG-welding
Welding material:
AlMg 5
Color:
Alu colored
Strut diameter x thickness:
16 x 2mm
Dimensions:
Length: 2 m
Width: 29 cm
Height: 25,70 cm
Weight:
8,20 kg
ALUTRUSS Truss Transport Board Combo for 3 Wheels
Maximum load:
6 truss systems vertical (height approx. 2.10 m)
Dimensions:
Length: 60 cm
Width: 30 cm
Height: 4,10 cm
Weight:
2,19 kg
ROADINGER Swivel Castor 100mm BLUE WHEEL light blue
Color:
Light blue
Dimensions:
Height: 12,8 cm
Diameter: Ø 10 cm
Weight:
660 g
ROADINGER Swivel Castor 100mm BLUE WHEEL with brake
Color:
Light blue
Dimensions:
Height: 12,8 cm
Diameter: Ø 10 cm
Weight:
930 g
ROADINGER Bolt Set for Wheels
Weight:
90 g
ALUTRUSS Truss Transport Ridge Combo
Material:
Birch multiplex, 30 mm
Dimensions:
Length: 60 cm
Width: 3 cm
Depth: 5 cm
Weight:
500 g
SHZ Clamping Belt S400 Ratchet 5m/25mm black
Standard:
EN 12195-2,
Lock:
Ratchet lock
Color:
Black
Dimensions:
Length: 5 m
Width: 2,50 cm
Weight:
300 g
