LED effect spotlight with RGB LEDs and stroboscope

• Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic
• 3 integrated show programs
• The device is cooled by passive convection cooling
• Control via DMX; Sound to light via Microphone; stand-alone
• With double bracket
• 4 digit 7-segment LED display
• 3 powerful LEDs 3 W high-power 3in1 TCL RGB (homogenous color mix)
• 18 powerful LEDs 0,5 W SMD 5730 cold white (CW)
• Strobe effect
• Preprogrammed in Light´J; LED PC-Control 512; Light Captain
• With a beam angle of 22°
• Silent operation

Package contents

• 1 x user manual

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
16 W
IP classification:
IP20
Protection class:
Protection class II
Power connection:
Fixed power supply cord with Euro plug
Lamp type:
LED lamp
LED:
3 x 3 W high-power 3in1 TCL RGB (homogenous color mix)
18 x 0,5 W SMD 5730 cold white (CW)
DMX channels:
7
DMX input:
1 x 3-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version
Cooling:
Passive convection cooling
Control:
DMX; Sound to light via Microphone; stand-alone
Preprogrammed in:
Light´J; LED PC-Control 512; Light Captain
Beam angle:
22°
Beam angle (1/2 peak):
22°
Beam angle (1/10 peak):
37°
Housing color:
Black
Attachment system:
Double bracket
Display type:
4 digit 7-segment LED display
Material:
Plastic
Dimensions:
Width: 15,2 cm
Depth: 12 cm
Height: 17 cm
Weight:
520 g
Noise classification:
Class 0 (no noise at all)
Power cord
Cable construction:
2 x 0,75 mm² H03VVH2-F
Cable length:
Approx. 0,9 m
Mounting bracket
Diameter mounting holes:
1 x Ø10mm
Material:
Metal, 1 mm
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
