Theater spot for halogen lamps with 300 or 500 watts power

• Professional theatre spot with color filter frame and protective grille
• Impressive light output
• Robust version
• Easy lamp replacement
• Antihalo lens for punctual illumination (light inside the beam is brighter than outside)
• Focus manual
• The device is cooled by passive convection cooling
• Control via plug and play
• With a beam angle of 5° - 45°
• With Mounting bracket
• Silent operation

Package contents

• 1 x spotlight, 1 x filter frame, 1 x user manual

Power supply:
230 V AC, 50 Hz
Power consumption:
Max. 500 W
IP classification:
IP20
Protection class:
Protection class I
Suitable lamp:
Max. 230 V/500 W Lamp envelope GY9.5
Power connection:
Fixed power supply cord with safety plug
Cable construction:
3 x 0,75 mm² H05SS-F
Cable length:
Approx. 0,9 m
Base:
GY9.5
Lamp type:
Halogen lamp
Equipment:
Focus manual
Color generation:
Via color filter frame
Cooling:
Passive convection cooling
Control:
Plug and play
Beam angle:
5° - 45°
Beam angle (1/2 peak):
5 - 20°
Beam angle (1/10 peak):
16 - 45°
Housing color:
Black
Attachment system:
Mounting bracket
Material:
Metal
Dimensions:
Length: 31 cm
Width: 23 cm
Height: 33 cm
Weight:
3,69 kg
Noise classification:
Class 0 (no noise at all)
Mounting bracket
Diameter mounting holes:
3 x Ø12mm
Material:
Metal, 3 mm
Filter frame
Diameter mounting holes:
2 x Ø10mm
Grid size:
22 x 22 mm
Material:
Metal, 0,5 mm
Dimensions:
Width: 16,8 cm
Height: 16,8 cm
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
