3-channel DJ mixer with Bluetooth and MP3 player

• 3 input channels with gain control, 3-band equalizer, cue button and channel fader
• DJ microphone channel with level control and 2-band equalizer
• Pre-fader listening to all input channels and the master output via adjustable stereo headphones output
• Crossfader with adjustable curve and reverse function
• Master channel with level control and 6-digit stereo LED level meter, switchable between master and PFL signal
• 6-digit stereo LED level meter
• 6 line and 2 phono inputs via RCA jacks
• Balanced XLR and RCA outputs
• Record output, independent of the master
• Control via Bluetooth
• LCD display
• Operating range up to 10m with line-of-sight
• Desktop console housing

Package contents

• 1 x mixer, 1 x user manual, 1 x power cord, 1 x rCA cable, 1 x declaration of conformity

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
25 W
Protection class:
Protection class II
Power connection:
Mains input via C8 (M) "figure 8" mounting version power supply cord with Euro plug (provided)
Control:
Bluetooth
Bluetooth:
Version: 4,2 + EDR
Profiles: A2DP, AVRCP
Bluetooth device name:
PM-322P
Audio player:
USB + Bluetooth,
Display type:
LCD display
Control elements:
Audio player, Crossfader, Cue-mix-function, source selector, Crossfade curve switch; Crossfade reverse switch
Status LED:
Switchable master level meter, clip, CUE, power
Connections:
Input: line via 4 x stereo RCA
Input: line/phono via 2 x stereo RCA
Input: Audio player via 1 x USB A (F) mounting version
Input: Microphone via 1 x 6.3 mm jack socket (mono) mounting version
Output: master via 2 x 3-pin XLR
Output: master via 2 x stereo RCA
Output: headphones via 1 x 6.3 mm jack socket (stereo) mounting version
Channels:
Input chanel: 1 x stereo with Line-line-player switch via RCA or player, channel control via fader, 3-band tone control EQ, gain control, CUE switch,
Input chanel: 2 x stereo with Line-Line/Phono switch via RCA, channel control via fader, 3-band tone control EQ, gain control, CUE switch,
Microphon chanal: 1 x mono via Jack, channel control via Rotary dial, 2-band tone control EQ, Cue-mix-function,
Master output: 1 x stereo via XLR or RCA, channel control via Rotary dial
Headphones output: 1 x stereo via Jack, channel control via Rotary dial
Music format:
MP3, WAV; WMA
Carrier frequency:
2,4 GHz
USB port:
Typ A
Range:
Range up to 10m with line-of-sight
Housing design:
Desktop console housing
Dimensions:
Length: 28,3 cm
Width: 23 cm
Height: 10,7 cm
Weight:
2,58 kg
Audio player
Available storage media:
USB devices max. 32GB (FAT 32)
