Mirror ball motor for mirror balls up to 50 cm diameter

• The maximum load always means the mirror ball weight including chains and the fixation material
• 2 chains and 4 quick links must be ordered separately
• 1 rotation per minute
• The motor always has to be installed with a secondary safety attachment
• Before taking into operation for the first time, the installation has to be approved by an expert
• Suitable for a mirror ball with a diameter of up to 50 cm
• For application areas such as: Clubs/dancing school
• For further information about this product, please refer to the Data Sheet under "Downloads"

Package contents

• 1 x motor, 1 x user manual

Power supply:
230 V AC, 50 Hz
Power consumption:
3,5 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Fixed Supply cord with open wires
Cable construction:
3 x 0,75 mm² H05VV-F
Cable length:
Approx. 0,9 m
Rotation:
1 RPM , 360 ° forward/backward
Maximum load:
10 kg
Max. mirror ball diameter:
50 cm (EUROLITE)
Housing color:
Black matte
Diameter mounting holes:
4 x Ø5mm; 2 x Ø10mm
Material:
Metal
Dimensions:
Height: 13 cm
Diameter: Ø 19 cm
Weight:
960 g
